EV-Bus 12m

Model EVBUS12
L*W*H 11980*2540*3280
Wheel base 5900
Range 641
Steering wheel position LHD/RHD
Max power 200kw
Motor type PMSM
Max Speed 69km/h
Battery 338.4kwh
Tire model 275/70R22.5
Color WHITE
MAX.SEATS 46

Description

Model EVBUS12
L*W*H 11980*2540*3280
Wheel base 5900
Overhang lengthFront/Rear 2680/3400
Curb Weight (kg) 12500
SEATS 22-46
Gross Weight 18000
Approach angle/departure angle 7°/7°
Tire Size 275/70R22.5
Battery Lithium Iron Phosphate
Battery Capacity (kwh) 338.4kwh
Motor Type PMSM
Max. Power(KW) 200/100
Max. Torque (N.m) 2650/1061
Max. Speed (km/h) 69
Max. Mileage (km) 641
Front/Rear Suspension Leaf spring with fewer leaves, 3 in the front and 4in the rear, front stabilizer bar
