| C22 EV PICKUP Specification |
| 车型 |
1030BEVR |
| Model Type |
| 基本参数 |
长/宽/高(mm) |
5330/1870/1864 |
|
|
| Basic parameters |
Length/width/height (mm) |
|
轴距(mm) |
3,100 |
|
Wheel base (mm) |
|
整备质量 |
1965 |
|
Curb Mass(kg) |
|
总重量 |
3000 |
|
Gross Weight(kg) |
|
前轮距(mm) |
1,580 |
|
front wheel base (mm) |
|
后轮距(mm) |
1,580 |
|
rear wheel base (mm) |
|
离地间隙(mm) |
208 |
|
|
|
Ground clearance (mm) |
|
座位数 |
5 |
|
QTY of Seats |
|
综合续航里程(km) |
300 |
|
Comprehensive mileage (km) |
|
悬挂系统(前/后) |
双横臂螺旋弹簧独立悬架/板簧非独立悬挂 |
|
Suspension system (front/rear) |
Double Wishbone Independent Suspension/leaf spring |
|
制动系统 |
前碟后鼓 |
|
|
Front Ventilated Disc/rear drum |
|
Braking system |
|
|
转向系统 |
电动液压助力式转向 |
|
|
Electric Hydraulic power steering |
|
Steering system |
|
|
轮胎型号 |
245/70R17 |
|
|
|
Tire model |
| 动力性能 |
电机 |
PMSM 永磁同步 |
|
electric motor |
Permanent magnet synchronous motor |
| Power Performance |
峰值功率（kW） |
120 |
|
Peak power (kw) |
|
峰值扭矩（Nm） |
350 |
|
Torque at Peak power |
|
充电（慢充） |
● |
|
charging(slow) |
|
充电（快充） |
● |
|
charging(fast) |
|
电池种类 |
磷酸铁锂 |
|
Battery type |
Lithium iron phosphate |
|
电量（kWh） |
≥59 |
|
Battery capacity |
| 豪华内饰Luxury interiors |
右置方向盘 |
● |
| Right hand drive |
| 一体式前大灯 |
● |
| integrated headlight |
| 外后视镜转向辅助灯 |
● |
| Steering auxiliary light of exterior rear-view mirror |
| 车内灯光关闭延迟 |
● |
| follow me home-ceiling light |
| 前/后 高穿透雾灯 |
– |
|
| Front/rear high penetration foglight |
| 外后视镜镜片电动调节功能 |
● |
| Electricadjusting function of exterior rear-view mirror |
| 高强度隔热玻璃 |
● |
|
| High strength insulating glass |
| 17寸双色铝合金轮毂 |
● |
| 17-inch aluminum alloy wheel hub |
| 全尺寸备胎（钢轮） |
● |
| full size spare wheel (steel rim) |
| 多功能方向盘 |
● |
|
| Multi-function steering wheel |
| 双向可调方向盘 |
● |
| up-down adjustable steering wheel |
| 前排安全带高度可调 |
● |
| Height adjustable seat belt-first row seat |
| 座椅面料 |
PU Leather |
| seat cover material |
| 主驾驶座 手动4向调节座椅 |
● |
| Manually 4-way adjustable main driver’s seat |
| 副驾驶座 手动4向调节座椅 |
● |
| Manually 4-way adjustable front passenger seat |
| 副驾驶遮阳板 |
● |
| co-driver side sunvisor |
| ABS刹车防抱死系统 |
● |
| Anti-lock brake system (ABS) |
| EBD电子制动力分配系统 |
● |
| Electronic brake force distribution |
| 倒车影像 |
● |
| reversing image |
| 正/副驾驶座双安全气囊 |
● |
|
| Driver/front passenger seat dual airbag |
| 驾驶座安全带未系提醒 |
● |
| Reminder of not fastening safety belt of driver seat |
| 中控锁+遥控钥匙 |
● |
| central remote |
| 第二排三点式安全带 |
● |
| three point seat belt at second row seat |
| 儿童安全锁 |
● |
|
| Child safety lock |
| 空调 |
● |
| AC |
| 电动车窗一键降 |
● |
| One-button down for door electric window |
| 前/后12V电源接口 |
● |
|
| Front/rear 12 V power interface |
| 9寸触控显示屏 |
● |
| 9-inch colorful touch screen |
| 蓝牙电话/音乐功能 |
● |
|
| Bluetooth phone/music function |
| MP3/MP4/USB功能接口 |
● |
|
| MP3/MP4/USB function interface |
| 扬声器 |
●/4 |
| Speaker |
| ●表示有此配备；”-“表示无此配备；”○”表示选装配备；本型录仅供参考，产品规格配备以实车为准； |
| ● means with the device; “-” means without the device; “○” means optional device; this catalog is for reference only, and product specifications shall subject to actual vehicle; |
